Description
Description
Features:
- Integrated point laser for incline measurement up to a distance of 30 m
- Strong magnets and two straps for securely fastening the instrument to workpieces
- Incline mechanism for fine adjustment on uneven surfaces
- Any value can be set as alternative 0°
- Angles can be adjusted manually to enable easy transfer
- Audio signal guides the user to the desired angle without having to look at the display
- Units of measure can be switched
- Automatically rotating display for better readability
Specifications:
- Length: 600mm
- Measurement range: 0 – 360° (4 x 90°)
- Electronics measurement accuracy:
- 0°/90°: ±0.05°
- 1°-89°: ±0.1°
- Laser working range: 30m
- Laser type: 635Nm. <1mW
- Laser class: II
- Levelling accuracy of laser: ±0.5
- Units of measurement: °. %. mm/m
- Tripod thread: 1/4
- Dimensions (L x W x H): 618mm x 27mm x 59mm
- Weight: 0.7kg
Warranty:
- 3 Years Warranty via registration Covered By Bosch Australia
Specification
Specifications
Part No | 601076900 |
---|---|
Barcode | 3165140803243 |
Brand | Bosch |
Warranty | 6 Year |
Net Weight (kg) | 1.4 |
Product Length (mm) | 659 |
Product Width (mm) | 88 |
Product Height (mm) | 68 |
